Sounder Beacon Base
This device combines a local-area sounder and a flashing beacon. It
has an integral isolator and base for a detector head. Detection is
thus co-located with both audible and visual alarms and short circuit
isolation.
45681-293 201-0119 45681-293
Multi-tone Open-area Sounder Beacons
The Intelligent Open Area Sounder Beacon is a loop powered, wall
mounted device offering a choice of three tones, Australian
(AS1670-4), New Zealand (NZS4512) and Europe (EN54-3) and
incorporates synchronisation of continuous and pulsed tones.
A nominal sound output of 100dB is achieved at a current
consumption 8mA. The beacon is activated whenever the sounder
is active and cannot be controlled separately. The acoustic self test
feature enables the sounder to listen to itself when switched on and
if no sound is detected, a fault signal will be transmitted to the
control panel.
