9 SPECIFICATIONS
Supply Voltage
Voltage
24VAC/DC ± 20%, 5W
Temperature Range
-20°C ≤ Ta ≤ 65°C
Relay Contacts
Contacts
2 x NO / 1 x NC / 2 x COM
Ratings
1A @ 110Vac – 1A @ 30Vdc (Resistive)
Earth Continuity Protection: AS/NZS 2081: 2011
Series Resistance Trip
Settings (± 3Ω)
10Ω, 15Ω, 20Ω, 25Ω, 35Ω, 45Ω
Shunt Resistance
1.25kΩ
Trip Time Settings
50ms, 100ms, 200ms, 300ms, 400ms, 500ms
Pilot Measurement Voltage
±24Vdc
Optional Start Button
100Ω, 1%, 5W
Mechanical
Dimensions
117x45x114mm
Weight
503g
IP Rating
IP20
10 EQUIPMENT LIST
Part Number
Description
167261
MEC-1 EARTH CONT
Accessories
115119
MODULE PTB PILOT TERMINATION FOR ECB/D/M
169732
RES 100R 5W 1%
NA
Normally Open Reset Button - Contact Ampcontrol
