4.1 Mechanical Arrangement
4.1.1 Enclosure
The MEC-1 is housed in a plastic enclosure and is rated IP20.
The dimensions are shown in Figure 1 below (117x45x114mm):
Figure 1: MEC-1 enclosure dimensions
4.1.2 Mounting arrangement
The MEC-1 enclosure is designed to be mounted on a standard 35mm DIN rail.
The pilot and earth connections are located at the top of the enclosure and the power and user inputs and outputs are located
at the bottom of the enclosure.
The fascia of the relay includes two (2) adjustable DIP switches and two (2) rotary switches for configuration of relay settings
and five (5) indication LEDs to assist in fault finding.
45
117
114
