Ampeg SVT-810E Owner's Manual

SVT-810E/AV Dual Bass Cabinet
2
What’s in the Box
SVT
®
-810E or SVT-810AV Speaker Cabinet, Quick Start Guide.
Introduction
Your Ampeg SVT-810E/AV Dual Bass Cabinet is a high quality speaker cabinet suitable for
all sizes of venues. The SVT-810E/AV can be “split” into two isolated 8 ohm, 4x10 cabinets
via the jackplate connections. This allows each cabinet to be driven by a separate amplier.
The cabinet features an industrial strength grip bar and heavy duty recessed wheels. Skid
rails are placed on the back of the enclosure to protect it while loading in and out of venues
and vehicles. (Place a foot against one of the rails to tilt the cabinet back.) Note that this
cabinet is available in two dierent grille cloth options: Classic black and white (SVT-810E)
or Anniversary blue and silver (SVT-810AV)—All specs and features are otherwise identical.
The Speakon
®
and 1/4" jacks are wired in parallel, allowing easy daisy chaining from one
speaker to another. Each of the jacks may be used as an input or a through connection.
Speakon connectors are recognized as the standard for professional installations, assuring
a secure, permanent connection that won’t corrode, vibrate loose or be easily tampered
with. The 1/4" jacks are convenient. However, the Speakon jacks are recommended when
using power ampliers over 150 watts, for permanent installations, or for the “rst” speaker
among a number of daisy chained speakers.
In order to get the most out of your new Ampeg speaker cabinet, please fully read this
Owner’s Manual, as well as the Important Safety Instructions included with your cabinet,
before you begin playing.
And thank you for choosing Ampeg.
TABLE OF CONTENTS
What’s in the Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Jackplate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Suggested Hookup Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Warranty and Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Ampeg SVT-810E Specifications

General

Amplifier class	-
Frequency range	58 - 5000 Hz
Audio output channels	- channels
Peak power per channel	800 W
Signal-to-Noise Ratio (SNR)	- dB
Total Harmonic Distortion (THD)	- %
Product color	Black
Connectivity technology	Wired
Package weight	74800 g

Weight and Dimensions

Depth	406.4 mm
Width	660.4 mm
Height	1219 mm
Weight	63500 g
