Electrical (23 °C ± 5 °C) < 75% RH
DC Voltage
RANGE Accuracy
400.0 mV ± (0.3% + 3dgts)
4.000V, 40.00V, 400.0V ± (0.5% + 3dgts)
600V ± (1.0% + 4dgts)
Resolution : 0.1 mV on 400 mV range
NMRR : >50dB @ 50/60Hz
CMRR : >20dB @ DC, 50/60Hz, Rs=1kΩ
Input Impedance : 10MΩ, 30pF nominal (1000MΩ for 400.0mV range)
Max input : 600VDC/VAC rms
AC Voltage
RANGE Frequency Accuracy
400.0mV
1)
50Hz to 500Hz ± (4.0% + 4dgts)
4.000V, 40.00V, 400.0V 50Hz to 60Hz ± (1.0% + 4dgts)
4.000V, 40.00V, 400.0V 60Hz to 500Hz ± (1.5% + 4dgts)
600V 50Hz to 500Hz ± (2.0% + 4dgts)
Resolution: 0.1 mV on 400 mV range
CMRR : >60db @ DC to 60Hz, Rs= 1kΩ
Input impedance: 10MΩ, 30pf nominal
Crest factor (ACDC-100 TRMS): < 1.6: at full scale; < 3.2: at half scale
Max input: 600VDC/VAC rms
1)
Selection by Range button manually, and is specified from AC 40mV (AC 60mV for ACDC-
100 TRMS) and up
Resistance
RANGE Accuracy
400.0Ω ± (0.8% + 6dgts)
4.000kΩ, 40.00kΩ, 400.0kΩ ± (0.6% + 4dgts)
4.000MΩ ± (1.0% + 4dgts)
40.00MΩ ± (2.0% + 4dgts)
Resolution: 0.1 Ω on 400 Ω range
Open Circuit Voltage : 0.4VDC typical
Continuity Tester
Open Circuit Voltage: 0.4Vdc typical
Range: 400.0Ω
Accuracy: ± (1.5% + 6dgts)
Audible threshold: between 10Ω and 120Ω.
Diode Tester
Open Circuit Voltage < 1.6 Vdc
Test Current (Typical) 0.4mA
