20
2) Specified with DC-zero mode applied to offset the non-zero residual
readings, if any
3) Add 10 LSD to the specified accuracy @ < 9 A
4) Maximum crest factor < 1.4:1 at full scale & < 2.8:1 at half scale
Frequency Hz
Function Sensitivity
1)
(Sine rms) Range
600 V, 1000 V 50 V 5.00 Hz to 999.9 Hz
60 A (Precise low current) 40 A 40.00 Hz to 400.0 Hz
60 A, 600 A, 1000 A 40 A 40.00 Hz to 400.0 Hz
Accuracy: ± (1.0 % + 5 LSD)
1)
DC-bias, if any, not more than 50% of Sine rms
& 3-Phase Rotation
measurement:
Voltage Range: 65 V to 600 V (sine wave only)
Frequency Range: 35 Hz to 400 Hz
measurement:
Voltage Range: 0.4 V to 600 V (sine wave only)
Frequency Range: 3 Hz to 400 Hz
Voltage Detection (NCV)
Typical Voltage Bar-graph Indication
20 V (tolerance: 10 V to 36 V) -
55 V (tolerance: 23 V to 83 V) - -
110 V (tolerance: 59 V to 165 V) - - -
220 V (tolerance: 124 V to 330 V) - - - -
440 V (tolerance: 250 V to 1000 V) - - - - -
Indication: bar-graph segments and audible beep tones proportional to the
field strength
Detection frequency: 50/60 Hz
Detection antenna: inside the top side of the stationary jaw
MAINTENANCE AND REPAIR
If the Meter fails to operate, check battery, test leads, etc., and replace as
necessary.
Double check the following:
1. Replace the fuse or battery if the meter does not work.
2. Review the operating instructions for possible mistakes in operating
procedure.
