17
Dimension
(L x W x H)
10.16 x 3.70 x 1.73 in (258 x 94 x 44 mm)
Weight 420 g (0.93 lb)
Jaw opening
& conductor
diameter
2.0 in (51 mm) max.
ELECTRICAL SPECIFICATIONS
Accuracy is ± (% reading digits + number of digits) or otherwise specified at
23°C ± 5°C.
Maximum Crest Factor < 2.5:1 at full scale & < 5:1 at half scale or otherwise
specified, and with frequency spectrum not exceeding the specified
frequency bandwidth for non-sinusoidal waveforms.
DC Voltage
Range Accuracy
600.0 V, 1000 V ± (0.8 % + 5 LSD)
Input Impedance: 10 MΩ, 100 pF nominal
AC Voltage (with Digital Low-Pass Filter)
Range Accuracy
600.0 V, 1000 V ± (0.8 % + 5 LSD) @ 50 Hz to 60 Hz
600.0 V, 1000 V ± (1.5 % + 5 LSD) @ 20 Hz to 200 Hz
600.0 V, 1000 V ± (10 % + 5 LSD) @ 200 Hz to 400 Hz
Input Impedance: 10 MΩ, 100 pF nominal
DC+AC Voltage (with Digital Low-Pass Filter)
Range Accuracy
600.0 V, 1000 V ± (1.0 % + 7 LSD) @ 50 Hz to 60 Hz
600.0 V, 1000 V ± (1.8 % + 7 LSD) @ DC, 40 Hz to 200 Hz
600.0 V, 1000 V ± (12 % + 7 LSD) @ 200 Hz to 400 Hz
Input Impedance: 10 MΩ, 100 pF nominal
PEAK-rms
Response: 80 ms to > 90 %
CREST (peak-hold)
Accuracy: add 250 digits to specified accuracy for changes > 5ms
Continuity
Audible Threshold: ON at ≤ 10 Ω ; OFF at > 250 Ω
Response time: 32ms approx.
