8
SPECIFICATION
Function Range
Temperature Range
0°F to 716°F
-18°C to 380°C
Accuracy With
ambient operating
temperature of 21°C
to 25°C (70°F to 77°F)
-18°C to 10°C (-0.4°F to 50°F): ±2%+1°C (2°F), or ±3°C
(±6°F), whichever is greater (Typical)
>10°C to 380°C (>50°F to 716°F): ±2%, or ±2°C (±4°F),
whichever is greater (Typical)
Repeatability
±0.5% of reading or ±0.5°C (±1°F), whichever is greater
(Typical)
Display Resolution 0.1°C / 0.1°F
Spectral Response 5μm to16μm
Laser Sighting Single point laser
Laser Power Output > 1mW Class 2, wavelength 630 to 670nm
Response Time (95%) 500ms
Distance to Spot (D:S) 10:1
Minimum Spot Size 20mm
Emissivity 0.95
Ambient Operating
Temperature
0°C to 50°C
32°F to 120°F
Relative Humidity 0% to 75% Non-condensing
Storage Temperature
-20°C to 65°C
-4°F to 150°F
(Battery not installed)
Temperature Display °C or °F selectable
Display Hold 8 sec
MAX/MIN
Temperature Display
√
Dual LCD Display √
LCD Backlit √
Low Battery
Indication
√
Power 9V 6F22 alkaline battery or equivalent
Battery Life
10 hours with laser and backlight on
30 hours with laser and backlight off
Dimension
(H x L x W)
Approximately 153 x 108 x 40 mm
(6.0 x 4.3 x 1.6 in)
Weight
Approximately 180 g (0.4 lb)
with battery installed
