IR-710 / IR-710-EUR 10:1 IR thermometer
SYMBOLS

Caution! Refer to the explanation in this manual.
Warning! Laser light. Do not stare into laser beam.
°C
Celsius.
°F
Fahrenheit.
Battery indication.

Complies with European directives.

Do not dispose of this product as unsorted municipal waste. Contact a
qualified recycler.

1
Laser Aperture
2
Trigger
3
Battery Cover
4
Display Hold
(After releasing the trigger)
5
Laser Indicator
4 8 5 6
9
7
1
2
3
10
6
Temperature Unit °C / °F
7
MAX / MIN Temperature
8
Display Backlight
9
Low Battery Indicator
10
Making Measurement
(pulling the trigger)
