Amtech Axpert-Eazy AMT-200-4 - MODE-C: Parameter Details

Axpert-Eazy AC Variable Frequency Drive
6-17
6
MODE-C Parameters
No.
Paramet
er
Unit
Def
Min
Max
Res
Description
WP
GROUP
-
1: PROGRAMMABLE INPUT/OUTPUT
C101 PSI-1 2 1 42 1 The different options are as under.
C102 PSI-2 10 1 42 1 =1: Not Used
=3: Ramp Select
=5: Preset i/p-1
=7: Freq Increase
=9: Aux Drive
=11: Fault Reset
=13: Reverse
=15: Ref Select 0
=17: PR Step Skip
=19: PR/RSF Reset
=21: PID Disable
=23: Ext Fault-NC
=25: Stop
=27: Drive Enable-NC
=29: PLC input 2
=31: PLC input 4
=33: PLC input 6
=35: PLC input 8
=37: Ready1 F/B
=39: Reverse Run
=41: Reverse Jog
=2: Jog Select
=4: Preset i/p-0
=6: Preset i/p-2
=8: Freq Decrease
=10: Emergncy Stop-NO
=12: Ext Fault-NO
=14: Terminal
=16: Ref Select 1
=18: PR Step Hold
=20: PID Bypass
=22: Emergncy Stop-NC
=24: Run
=26: Drive Enbl-NO/STO
=28: PLC input 1
=30: PLC input 3
=32: PLC input 5
=34: PLC input 7
=36: Torque Mode
=38: Forward Run
=40: Forward Jog
=42: MBRK Answer
C103 PSI-3 11 1 42 1
C104 PSI-4 4 1 42 1
C105 PSI-5 5 1 42 1
C106 PSI-6 6 1 42 1
C107 PSO-1 2 1 40 1 The different options are as under.
C108 PSO-2 6 1 40 1 =1: Not Used
=3: Local
=5: I-Detection
=7: Speed Detect1
=9: Acceleration
=11: Aux Drive
=13: Zero Speed
=15: PID Up Limit
=17: Temp Alarm
=19: Pump-1
=21: Pump-3
=23: Doff-End Alarm
=25: Fault
=27: PLC Output 2
=29: PLC Output 4
=31: PLC Output 6
=33: PID F/B ULmt
=35: FAN Control
=37: MBRK
=39: STO Feedback
=2: Run
=4: Reverse Run
=6: Freq Attain
=8: Speed Detect2
=10: Deceleration
=12: Timer Output
=14: Fault Alarm
=16: PID Lo Limit
=18: Ready
=20: Pump-2
=22: Pump-4
=24: Sleep Mode
=26: PLC Output 1
=28: PLC Output 3
=30: PLC Output 5
=32: PLC Output 7
=34: PID F/B LLmt
=36: Ready1
=38: KEB ON
=40: Panel Temp Alarm
C109 PSO-3 1 1 40 1
C110 PSO-4 1 1 40 1
C111 Programmable
Relay1
2 1 40 1
C112 Programmable
Relay2
1 1 40 1
C113 Programmable
Fault Relay
25 1 40 1
C114 PSI-RUN 24 1 42 1 The different options are same as PSI option.
C115 PSI-STOP 25 1 42 1
GROUP
-
2: ANALOG OUTPUT SELECTION
C201 Vout-1 1 1 15 1 This configures the function of analog output.
C202 Vout-2 2 1 15 1 =1: Output Frequency
=3: Output Power
=5: DC Bus Volt
=7: Heat sink Temp
=9: PLC A-O/P 2
=11: PLC A-O/P 4
=13: Excitation
Current
=15: Bi Trq Cur
=2: Output Current
=4: Output Voltage
=6: PID Output
=8: PLC A-O/P 1
=10: PLC A-O/P 3
=12: Uni Trq Cur
=14: Set Frequency
C203 Iout-1 3 1 15 1
C204 Iout-2 4 1 15 1
C205 Vout-1 Gain 1.000 0.100 2.500 0.001 This is gain setting for the VO1 analog output.
