Amtech Axpert-Eazy AMT-315-4 - User Manual

242 pages

Save Page as PDF

To Next Page

To Next Page

Loading...

NOTICE

1. Read this manual thoroughly before using the Axpert-Eazy, and store in a safe place for reference.

2. Make sure that this manual is delivered to the final user.

200 V System, 11 kW (15 Hp) ~ 90 kW (125 Hp)

400 V System, 22 kW (30 Hp) ~ 1550 kW (2075 Hp)

500 V System, 30 kW (40 Hp) ~ 1550 kW (2075 Hp)

600 V System, 30 kW (40 Hp) ~ 1800 kW (2415 Hp)

Instruction Manual

Axpert-Eazy Series

AMTECH

IMAE-01, Rev. 1.20

JUL 2017

AMTECH

Table of Contents

Questions and Answers

P
Perry ColemanSep 5, 2025
What causes Output Current Unbalance in Amtech DC Drives?
- J
  Jeffery LynchSep 5, 2025
  Output Current Unbalance in Amtech DC Drives can stem from various factors. Ensure that the parameters are set properly. Abnormal setting of V/F, Torque Boost, Acceleration time and Speed search function related parameters and current limit may result in output current unbalance. Increase the acceleration time (A201 / A203). If fault occurs during deceleration, increase the deceleration time (A202 / A204). Abnormal setting of DC braking parameters can result in unbalance current fault during deceleration. Reduce the dc braking start frequency (A306) and dc braking time (A308) settings if used.
H
hectorvalenciaNov 19, 2025
What to do if Amtech Axpert-Eazy AMT-315-4 DC Drives show an Over Current Fault?
- C
  Christina ReidNov 19, 2025
  If your Amtech DC Drive displays an Over Current Fault, several issues could be the cause. First, the power module(s) in the main circuit might be damaged, so switch off the power supply and check them. Second, there may be a loose or improper connection of the current sensor cable, or a short in the cable. In this case, switch off the power supply, remove the cable, and inspect it for proper crimping on both sides. Reinsert the cable securely. If the issue persists, replace the cable. Third, the current sensor itself may have failed, so switch off the power supply, remove the current sensor, and check. If no fault is observed, replace the damaged current sensor. Fourth, the fault may originate from the Driver Board. Switch off the power supply and remove the FRC (in case of wire interface...
B
Brendan DukeSep 18, 2025
What to do if Amtech Axpert-Eazy AMT-315-4 show an EEPROM Fault?
- C
  Christine ThomasSep 18, 2025
  If your Amtech DC Drive is showing an EEPROM Fault, it means the data received from the EEPROM is incorrect or out of range. On fault reset, default values will be stored in the EEPROM. If the fault occurs again after power recycling, replace PCA-2014A.
J
Juan MillerSep 16, 2025
How to troubleshoot Auto Tuning Fault in Amtech Axpert-Eazy AMT-315-4?
- K
  Kathleen MaynardSep 16, 2025
  If you encounter an Auto Tuning Fault in your Amtech DC Drive, it means the auto-tuning process has failed. The motor parameter setting value may be incorrect, so set the correct motor parameter. Ensure that the motor is directly connected to the inverter, removing any additional components like output chokes during auto-tuning.
C
Christine TranSep 14, 2025
What to do if Amtech DC Drives show an External Fault?
- C
  Christopher ChandlerSep 14, 2025
  If your Amtech DC Drive displays an External Fault, the signal for the external fault is present at the PSI. Check and correct it. If the signal is not present, remove the selection of the external fault with the help of Mode-C parameters. There may be a problem in PCA-2014A, so remove the control board PCA-2014A.
H
hillmatthewSep 12, 2025
What does Reference Missing mean on Amtech Axpert-Eazy AMT-315-4?
- S
  Steven BrownSep 12, 2025
  If your Amtech DC Drive shows Reference Missing, the analog current input reference (4-20 mA) to the unit is below 3 mA. Check the voltage level at FSI terminal of PCA-2014A.
M
moorerodneySep 12, 2025
What causes Under Current Fault in Amtech Axpert-Eazy AMT-315-4 DC Drives?
- K
  Kimberly DouglasSep 12, 2025
  An Under Current Fault in Amtech DC Drives may occur if the Under Current Limit B304 is set too low. Disable the feature by setting 0% in B304.
N
Nathan KnappSep 9, 2025
What to do if my Amtech Axpert-Eazy AMT-315-4 have Charging Fault?
- K
  Kimberly BakerSep 9, 2025
  If your Amtech DC Drive displays a Charging Fault, the DC bus voltage didn’t reach the predefined voltage level within 5 seconds after power up. The soft charge resistor may be open. One or more phases may have failed. DC bus voltage feedback may be missing. Ensure proper connection of DC bus voltage feedback at J9.
M
Mary PrattSep 7, 2025
What to do if Amtech Axpert-Eazy AMT-315-4 show an Output Phase Loss?
- D
  Dawn HansonSep 7, 2025
  If your Amtech DC Drive indicates an Output Phase Loss, it could be due to a single phasing of the motor, so disconnect and check the motor. It can also happen if one or more output cables are open or loosely connected, so check the output connections and correct it.
H
Haley DavisAug 22, 2025
What causes Amtech Axpert-Eazy AMT-315-4 to have an Over Voltage Fault?
- C
  Carolyn SullivanAug 22, 2025
  An Over Voltage Fault in Amtech DC Drives can occur if the power supply voltage rises above specified limits (785 VDC for 400 V series, 965 VDC for 500 V series, or 1160 VDC for 600 V series). Reduce the voltage to stay within the correct range. It can also happen if the speed is fluctuating.
