Product Information
2
AXB-VOL3 Three-Channel Volume Control
AXB-VOL3 Specifications (Cont.)
Front Panel Components:
AXlink LED AXlink LED (green and blinks to indicate AXlink communication activity and
power:
• Full-Off indicates no power is being received or the controller is not functioning
properly.
• One blink per second indicates power is active and AXlink communication is
functioning.
• Full-On indicates there is no AXlink control or activity, but power is On.
Device DIP Switch An 8-position DIP switch used to set the AXlink device number for the
AXB-VOL3.
Channel LEDs Red channel LEDs 1 - 3. The LEDs individually light indicating a change in chan-
nel levels.
Rear Panel Components:
AXlink connector 4-pin, captive wire connector, receives power and information via the AXlink and
AXlink Central Controller.
Volume Channel
connectors
6-pin, captive wire connectors that control audio level, audio mute, variable ramp
speed and level presets of up to 3 devices.
Enclosure Metal with black matte finish
Dimensions (HWD) 1.51" x 5.55" x 5.45" (3.84 cm x 14.10 cm x 13.84 cm)
Weight 1.1 lb (0.499 kg)
AXlink Power 12 VDC @ 230 mA
