Integrated Master – NetLinx® Programming
189
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
CI<input>O<output>
Switches both the audio and
video input port to the output
port.
IMPORTANT: This command must be sent to D:P:S port 1.
Syntax:
SEND_COMMAND <DEV>, "'CI<input>O<output>'"
Variables:
input = The source input port number to switch from.
output = The destination output port number to switch to.
Examples:
SEND_COMMAND 5002:1:0, "'CI2O1'"
Switch (audio/video) input port #2 to output #1.
SEND_COMMAND 5002:1:0, "'CI3O1,2'"
Switch (audio/video) input port #3 to outputs #1 and #2.
SEND_COMMAND 5002:1:0, "'CI0O1,2,3'"
Disconnects output ports #1, #2, and #3.
CL<L#>I<I#>O<O#> Syntax:
SEND_COMMAND <DEV>, "'CL<Switch Level>I<Input>O<Outputs>'"
Variables:
switch level = ALL, VIDEO, AUDIO
input = The source input port number to switch from.
(Input of “0” acts as a disconnect for the routed Output(s))
output = The destination output port number to switch to.
?EXT_AUD
Requests the functional status of
the Audio Switching Boards.
NOTE: This command does not
apply to AIE Boards.
NOTE: Returns TRUE only when the ASB cards are all inserted properly and the HSSI cable is
attached (as directed for 800/1600/3200 systems).
Syntax:
SEND_COMMAND <DEV>, "'?EXT_AUD'"
Example:
SEND_COMMAND 5002:1:0,"'?EXT_AUD'"
Returns a response of the form: TRUE|FALSE
?FAN_ALARM
Requests the Fan Alarm State of
the Switcher.
NOTE: The fan alarm is triggered by one or more slow or stopped fan unit.
Syntax:
SEND_COMMAND <DEV>, "'?FAN_ALARM'"
Example:
SEND_COMMAND 5002:1:0, "'?FAN_ALARM'"
Returns a response of the form: ON|OFF
?FAN_SPEED
Requests the speed of the fans
inside the Enova DGX Switcher.
Syntax:
SEND_COMMAND <DEV>, "'?FAN_SPEED-<Fan>'"
Variable:
Fan = Fan is an optional command, to query a specific fan
Example:
SEND_COMMAND 5002:1:0,"'?FAN_SPEED'"
Returns a COMMAND string of the form: FAN_SPEED-[<Fan1>,<Fan2>,..<FanN>]
Example:
SEND_COMMAND 5002:1:0,"'?FAN_SPEED-1'"
Returns a COMMAND string of the form: FAN_SPEED-1,<Fan1>
?FG
Requests the Switcher’s FG
Number.
Syntax:
SEND_COMMAND <DEV>, "'?FG'"
Example:
SEND_COMMAND 5002:1:0, "'?FG'"
?IFCONFIG
Requests interface configuration
settings.
NOTE: All changes to IP settings require a system reboot to take effect.
Syntax:
SEND_COMMAND <DEV>, "'?IFCONFIG-1'"
Example:
SEND_COMMAND 5002:1:0, "'?IFCONFIG-1'"
Returns a COMMAND string of the form: SEND_COMMAND 5002:1:0, "'IFCONFIG-
1,UP,S,ip=10.35.91.228,gw=10.35.90.1,mask=255.255.255.0,hn=mydgx'"
Switcher SEND_COMMANDs
