Enova DGX HDMI Boards
64
Hardware Reference Manual – Enova DGX 100 Series Digital Media Switchers
Audio Resolution 16 bit to 24 bit
Audio Sample Rate 32 kHz, 44.1 kHz, 48 kHz, 96 kHz, 192 kHz
Local Audio Support Yes, insertion and/or extraction of 2 CH L-PCM selectable by channel
DDC/EDID Support • EDID provided by Enova DGX Digital Media Switcher
• EDID is user re-programmable
HDCP Support Yes, full matrix HDCP 1.4 support (includes any input to any or all outputs)
• Key Management System
• AMX HDCP InstaGate Pro® Technology
• Key support up to 16 devices per output, independent of source device
CEC Support None
Output +5 V DDC Pin 50 mA max. per output port
Input Propagation Delay 2 μs
Output Propagation Delay 24 ms for progressive, 48 ms for interlaced, 5 μs when in Bypass mode
HDMI Audio Synchronization
(Embedded Audio)
Progressive and Interlaced Video Formats @ 60 Hz frame rate: Audio is actively delayed to match
video within 8 ms leading or lagging
NOTE: Interlaced and progressive video supported into the HDMI Input Board, progressive only
supported out of the HDMI Output Board unless in non-scaling Bypass mode.
HDMI Audio Synchronization
(Switched Audio)
Progressive and Interlaced Video Formats @ 60Hz frame rate: Audio lags video by up to 22ms.
Audio Switching Board Support • Supports break-away audio switching of 2 CH L-PCM for all channels
• Supports downmix from one input channel of Dolby True-HD, Dolby Digital, DTS-HD, DTS, or 2 to
8 channel L-PCM
Connectors 4 HDMI Type A female ports
HDMI Specifications
To Next Page
