AMX MCP-106 - Knob - Button 11; Knob - Buttons 12-13; Navigation Wheel - Level Control; Display Bargraph

Programming
35
Instruction Manual - Massio ControlPads and Keypads
Knob - Button 11
The knob is a pushbutton that provide an event on Channel #11, and can be programmed like any other button.
Knob - Buttons 12-13
The knob itself can be rotated clockwise and counterclockwise, and is intended to provide level control (for example volume or
lighting levels).
When rotated clockwise, the knob provides events on Channel #12.
When rotated counter-clockwise, the knob provides events on Channel #13.
When rotated (clockwise/counter-clockwise), the knob provides level events on Level #2.
Navigation Wheel - Level Control
In addition to generating button events, a rotation of the knob causes a level change on Level #2:
Clockwise rotations increase the level
Counter-clockwise rotations decrease the level.
Example code is provided below:
LEVEL_EVENT[dvMassio,2]
{
volume = level.value
SEND_STRING 0, “’Volume is now: ‘, ITOA(volume)”
}
Display Bargraph
The display bargraph consists of 7 LEDs and is controlled via Level #1. Sending a level will update the LEDs on the display bargraph.
Example code is provided below:
SEND_LEVEL dvMassio,1,200
Supported SEND_LEVELs
MKP-108 keypads support a SEND_LEVEL on Level #1. This level is used to adjust the LED bargraph display on the keypad.
Supported SEND_COMMANDs
SEND_LEVELs
SEND_LEVEL Adjusts the LED bargraph display on the keypad.
Syntax:
SEND_LEVEL <device address>,1,<level>
Variables:
level = LED bargraph display (range = 0 - 255).
