MCP-108
The following table lists the specifications for the MCP-108:
MCP-108 Specifications
Ge n e r a l :
Dimensions (HWD): 4 11/16" x 6" x 1" (119 mm x 152.5 mm x 26 mm)
Weight: Approximately 0.41 lb (0.19 kg)
Mounting Options: Mount onto standard 2 gang US, UK, or EU back boxes
Front Panel Components: • 8 Buttons
• 1 Volume Knob with Push Mute
• 7 LED Bar Graph Indicator
Colors Available: • Black: MCP-108-BL (FG2102-08-B)
• White: MCP-108-WH (FG2102-08-W)
Active Power Requirements:
Voltage, DC (Typical): PoE (37V-57V)
Voltage DC Range: 37V-57V per 802.3af specification
Power Connector: (1) RJ-45 Ethernet
Power Supply:
External, Required: Any POE injector or switch, conforming to the 802.3af standard including AMX’s PS-POE-AF-TC (FG423-83),
not included
Environmental:
Temperature (Operating): 32º F to 104º F (0º C to 40º C)
Temperature (Storage): 14º F to 140º F (-10º C to 60º C)
Humidity (Operating): 5% to 85% RH
Ethernet:
Ethernet Connection: (1) 10/100; Port provides TCP/IP communication. This is an Auto MDI/MDI-X enabled port, which allows
you to use either straight-through or crossover Ethernet cables. The Ethernet Port LEDs show
communication activity, connection status, speeds, and mode information.
Control Ports and Indicators:
RS-232 Port: (2) 3-position 3.5mm Screw Terminals; 300 - 115,200 baud
IR/Serial Port: (2) 2-position 3.5mm Screw Terminals; IR Transmit / 1-way Serial ports
Support high-frequency carriers up to 1.142 MHz
I/O Channels: (1) 4-position 3.5 mm Screw Terminal; 2-channel binary I/O port for contact closure with each input being
capable of voltage sensing
Relay Connection: (1) 4-position 3.5mm Screw Terminal; (2) single-pole, single-throw relays
Each relay can switch up to 24 V
DC
or 28 V
AC
@ 1 A
Each relay is independently controlled
Program Port: (1) USB Mini-B, USB
ID Pushbutton Reset factory settings, reset factory image, toggle between DHCP or static IP addressing mode
Memory:
Flash: 4 GB
Memory Card: 4 GB SD
DDRAM: 256 MB
Certifications: • FCC Class B
• CE EN 55022
•EN 55024
•IEC/EN-60950-1
• UL 60950-1
To Next Page
