Error code
displayed
on
joystick
with color
screen
Error code on joystick
with LED display
(indicator lights)
Number of
flashes of
indicator
light on e-bx
• The center mount
legrest actuator is
defective, or actuator
ID card is faulty.
• More than one center
mount legrest
actuator (#4)
connected to the
same e-bx.
7. If an actuator must be replaced, execute a position reset for the
new actuator. Refer to section 3, E-bx special boot-up modes and
position reset.
8. If an entire module must be replaced (tilt, recline, seat elevate,
legrests), a position reset is not necessary because the new
module has been factory-calibrated and the actuator would not
have been disrupted during transportation or installation of
module onto the chair.
• The left legrest or left
stander actuator is
defective, or actuator
ID card is faulty.
• More than one left
legrest or left stander
actuator (#5)
connected to the
same e-bx.
• The right legrest or
right stander actuator
is defective, or
actuator ID card is
faulty.
• More than one right
legrest or right
stander actuator (#6)
connected to the
same e-bx.
• Failed factory test.
• Internal memory is
corrupted or
defective.
1. Reset alarm by turning chair off and back on, making sure the
error does not reoccur.
2. If the problem persists, replace the e-bx.
Internal problem in
the e-bx.
1. Reset alarm by turning chair off and back on, making sure the
error does not reoccur.
2. If the problem persists, replace the e-bx.
Communication
problem between the
e-bx and the R-Net
power module.
1. Reset alarm by turning chair off and back on, making sure the
error does not reoccur.
2. If the problem persists, replace the e-bx.
In the event that all the instructions in the “Problem solving” column of the above table have been carried out and
the problem (s) persist(s), contact Amylior’s technical support by email at techsupport@amylior.com or by phone at
1 888 453-0311
