• If the reading result is between 23.5 Volts and 27.5 Volts, check the cable as well as the connections
between the battery and the R-Net power module.
• If the total battery voltage reading is near 0 Volts, inspect the battery protection devices by checking the
electrical continuity of the circuit breaker. Turn dial to Ohmmeter on the multimeter. To avoid false
readings, be sure to properly connect probes to desired jacks for a reliable resistance reading.
• Connect the end of the probes together and wait for the reading on the multimeter to stabilize. Ideally,
the reading should be 0.0 Ohms. If the value is around 0.1 Ohms, write down this value, as it becomes the
reference value equal to 0.0 Ohms. If the multimeter has a "rel" mode, activate it while the two probes
are touching each other and once the value has stabilized. This mode will correct the value to 0.0 Ohms
for a strong contact.
