EVAL-ADAU1701MINIZ
Rev. 0 | Page 11 of 12
Item Qty Reference Designator Description Manufacturer Part Number
26 10
R1, R17, R21, R23, R24, 25, R27,
R28, R29, R31
Chip resistor 1%, 63 mW, thick
film (0402), 10.0 kΩ
Rohm MCR01MZPF1002
27 4 R10, R14, R32, R33
Chip resistor 1%, 63 mW, thick
film (0402), 562 Ω
Vishay/Dale CRCW0402562RFKED
28 2 R11, R12
Chip resistor 1%, 63 mW, thick
film (0402), 56.2 Ω
Vishay/Dale CRCW040256R2FKED
29 1 R13
Chip resistor 1%, 63 mW, thick
film (0402), 475 Ω
Vishay/Dale CRCW0402475RFKED
30 2 R15, R20
Chip resistor 1%, 63 mW, thick
film (0402), 8.06 Ω
Rohm CRCW04028K06FKED
31 1 R16
Chip resistor 1%, 63 mW, thick
film (0402), 18.2 kΩ
Vishay/Dale CRCW040218K2FKED
32 1 R22
Chip resistor 1%, 63 mW, thick
film (0402), 100 Ω
Rohm MCR01MZPF1000
33 4 R2, R3, R4, R5
Chip resistor 1%, 63mW, thick
film (0402), 13.0 kΩ
Rohm MCR01MZPF1302
34 1 R26
Chip resistor 1%, 63mW, thick
film (0402), 1.00 kΩ
Panasonic ECG ERJ-2RKF1001X
35 1 R30
20.0 kΩ potentiometer, 9 mm
vertical
Panasonic ECG EVU-F2MFL3B24
36 1 R6
Chip resistor 1%, 63 mW, thick
film (0402), 78.7 kΩ
Vishay/Dale CRCW040278R7FKED
37 1 R7
Chip resistor 1%, 63 mW, thick
film (0402), 140 kΩ
Panasonic ECG ERJ-2RKF1403X
38 4 R8, R9, R18, R19
Chip resistor 1%, 63 mW, thick
film (0402), 49.9 kΩ
Vishay/Dale CRCW040249K9FKED
39 2 S1, S5 SPDT slide switch PC mount E-Switch EG1271
40 4 S2, S3, S4, S6
Tact switch long stroke
(normally open)
Omron Electronics B3M-6009
41 1 U1
2 W, filterless Class-D, stereo
audio amplifier
Analog Devices SSM2306CPZ
42 1 U2
Adjustable low dropout
voltage regulator
Analog Devices ADP3336ARMZ-REEL7
43 1 U3
SigmaDSP 28-/56-bit, audio
processor with 2 ADC/4 DAC
Analog Devices ADAU1701JSTZ
44 1 U4
μP voltage supervisor, logic
low reset output
Analog Devices ADM811TARTZ-REEL7
45 1 U5
256 K I
2
C™ CMOS serial
EEPROM
Microchip 24AA256-I/ST
46 1 Y1 Crystal 12.288 MHz SMT, 18 pF Abracon Corp ABM3B-12.288MHZ-10-1-U-T
