ITEM REF_DES DNI/DNP QTY MFG PART # MANUFACTURER VALUE DESCRIPTION
1
1V8, 3V3, GND1, GND2, J_CSB,
J_SDI, J_SDO, J_SYS, BB_SEL,
J_INTB, J_SCLK, J_INT2B, J_EXT_PWR
- 13 PCC03SAAN SULLINS PCC03SAAN
CONNECTOR; MALE; THROUGH HOLE; BREAKAWAY;
STRAIGHT THROUGH; 3PINS; -65 DEGC TO +125 DEGC
2
BB, BIN, BIP, CSB, SDI, SDO, VBG, VCM,
AGND, AOUT, DRVN, DRVP, ECGN, ECGP,
FCLK, INTB, SCLK, VREF, AGND1-AGND4,
INT2B, RBIAS, FTHR_GND, BUFF1_OUT
- 26 5011 KEYSTONE N/A
TEST POINT; PIN DIA=0.125IN; TOTAL LENGTH=0.445IN;
BOARD HOLE=0.063IN; BLACK;
PHOSPHOR BRONZE WIRE SILVER PLATE FINISH;
3 AVDD, DVDD, OVDD, EXT_PWR - 4 5010 KEYSTONE N/A TESTPOINT WITH 1.80MM HOLE DIA, RED, MULTIPURPOSE;
4
RN, RP, P_UP, BP_BN, DN_BN, DP_BP, EN_BN,
EP_BP, EP_EN, J_BIN, J_BIP, J_AVDD, J_DRVN,
J_DRVP, J_DVDD, J_ECGN, J_ECGP, J_OVDD,
P_DOWN, J_RBIAS, XTL_PWR, BUFF1_IN,
EN_UNBAL, EP_UNBAL, ONBRD_FCLK
- 25 5-146280-2 TE CONNECTIVITY 5-146280-2
CONNECTOR; MALE; THROUGH HOLE; HEADER ASSEMBLY;
MOD II; BREAKWAY; SINGLE ROW; HIGH TEMPERATURE;
VERTICAL W/ 0.025 SQ POST; 0.100 C; STRAIGHT; 2PINS
5 C1-C3, C30 - 4 C0805C473J3GAC KEMET 0.047UF
CAPACITOR; SMT (0805); CERAMIC CHIP; 0.047UF; 25V;
TOL=5%; TG=-55 DEGC TO +125 DEGC; TC=C0G
6 C4 - 1 UMK107AB7105KA TAIYO YUDEN 1UF
CAPACITOR; SMT (0603); CERAMIC CHIP; 1UF; 50V;
TOL=10%; TG=-55 DEGC TO +125 DEGC; TC=X7R
7 C5-C7, C16-C21, C23 - 10 GRM188R61E106MA73 MURATA 10UF
CAPACITOR; SMT (0603); CERAMIC CHIP; 10UF; 25V;
TOL=20%; TG=-55 DEGC TO +85 DEGC; TC=X5R; GRM SERIES; MURATA
8 C9, C10, C14, C15 - 4 C3216X7R1H335M160AC TDK 3.3UF
CAPACITOR; SMT (1206); CERAMIC CHIP; 3.3UF; 50V;
TOL=20%; MODEL=C SERIES; TG=-55 DEGC TO +125 DEGC; TC=X7R
9 C11-C13, C22 - 4 C1608X7R1E104K080AA TDK 0.1UF
CAPACITOR; SMT (0603); CERAMIC CHIP; 0.1UF; 25V;
TOL=10%; MODEL=C SERIES; TG=-55 DEGC TO +125 DEGC; TC=X7R
10 C27, C31 - 2
GRM31CR72A225KA73;
KRM31KR72A225KH01
MURATA 2.2UF
CAPACITOR; SMT (1206); CERAMIC CHIP; 2.2UF; 100V;
TOL=10%; MODEL=GRM SERIES; TG=-55 DEGC TO +125 DEGC; TC=X7R
11 C32 - 1 C0603C102J5GAC; 06035A102JAT2A KEMET/AVX/MURATA 1000PF
CAPACITOR; SMT; 0603; CERAMIC; 1000pF; 50V; 5%;
C0G; -55degC to +125degC
12
C_BB, C_BIN, C_BIP, C_DRVN, C_DRVP,
C_ECGN, C_ECGP
- 7 41828-50 PLASTICS ONE 41828-50
CONNECTOR; FEMALE; THROUGH HOLE; JACK; PCB; 1.5MM;
TOUCHPROOF WAVE SOLDER VERSION WITH STAMPING; RIGHT ANGLE; 3PINS
13 D1 - 1 LTST-C194KGKT LITE-ON ELECTRONICS INC LTST-C194KGKT
DIODE; LED; SMD CHIP LED; WATER CLEAR LENS;
AlInGaP GREEN; GREEN; SMT (0603); VF=2.1V; IF=0.02A
14 J8 - 1 PPPC161LFBN-RC SULLINS ELECTRONICS CORP. PPPC161LFBN-RC
CONNECTOR; FEMALE; THROUGH HOLE; LFB SERIES;
2.54MM CONTACT CENTER; STRAIGHT; 16PINS
15 J9 - 1 PPPC121LFBN-RC SULLINS ELECTRONICS CORP PPPC121LFBN-RC
CONNECTOR; FEMALE; THROUGH HOLE;
HEADER FEMALE; STRAIGHT; 12PINS
16 R1, R31 - 2 ERA-6ARW513 PANASONIC 51K RESISTOR; 0805; 51K OHM; 0.05%; 10PPM; 0.125W; THIN FILM
17 R2, R3 - 2 CRCW06031001FK; ERJ-3EKF1001V VISHAY DALE; PANASONIC 1K RESISTOR; 0603; 1K; 1%; 100PPM; 0.10W; THICK FILM
18 R4, R10 - 2 3296Y-202LF BOURNS 2K
RESISTOR; THROUGH HOLE-RADIAL LEAD;
3296Y SERIES; 2K OHM; 10%; 100PPM; 0.5W
19 R5, R6 - 2 CRCW06031K33FK VISHAY DALE 1.33K RESISTOR; 0603; 1.33K; 1%; 100PPM; 0.10W; THICK FILM
20 R7 - 1 3296Y-1-103LF BOURNS 10K
RESISTOR; THROUGH-HOLE; 10K OHM; 10%;
100PPM; 0.5W; MOLDER CERAMIC OVER METAL FILM
21 R9, R11, R36 - 3 CRCW06031003FK; ERJ-3EKF1003 VISHAY DALE/PANASONIC 100K RESISTOR; 0603; 100K; 1%; 100PPM; 0.10W; THICK FILM
22 R12 - 1 RN73C1J324KB; 4-1879135-8 TE CONNECTIVITY 324K RESISTOR; 0603; 324K OHM; 0.1%; 10PPM; 0.063W; THIN FILM
23 R13, R18, R19, R28 - 4 RG1608P-101-B-T5; ERA-3YEB101V SUSUMU CO LTD./PANASONIC 100 RESISTOR; 0603; 100 OHM; 0.1%; 25PPM; 0.1W; THICK FILM
24 R14 - 1 RG1608P-471-B-T5 SUSUMU CO LTD. 470 RESISTOR; 0603; 470 OHM; 0.1%; 25PPM; 0.10W; THICK FILM
25 R20, R25 - 2 ERA-3ARB103 PANASONIC 10K RESISTOR; 0603; 10K OHM; 0.1%; 10PPM; 0.1W; THIN FILM
26 R26, R27, R29, R30 - 4
CRCW06030000ZS; MCR03EZPJ000;
ERJ-3GEY0R00
VISHAY DALE/ROHM/
PANASONIC
0 RESISTOR; 0603; 0 OHM; 0%; JUMPER; 0.10W; THICK FILM
27 U1 - 1 MAX30001CWV+
ANALOG DEVICES
MAX30001CWV+
EVKIT PART-IC; MAX30001; ULTRA-LOW POWER;
SINGLE-CHANNEL INTEGRATED BIOPOTENTIAL
AND BIOIMPEDANCE AFE; PACKAGE OUTLINE: 21-100074;
PACKAGE CODE: W302L2+1; WLP30
28 U2 - 1 MAX1806EUA18+
ANALOG DEVICES
MAX1806EUA18+ IC; VREG; LOW-VOLTAGE LINEAR REGULATOR; UMAX8-EP
29 U3 - 1 MAX8512EXK
ANALOG DEVICES
MAX8512EXK IC, VREG, Ultra-Low-Noise, High PSRR, Adjustable Vout, SC70-5
30 U4 - 1 MAX44263AXA+
ANALOG DEVICES
MAX44263AXA+
IC; OPAMP; 1.8V; 15MHZ LOW-OFFSET; LOW-POWER;
RAIL-TO-RAIL I/O DUAL OPERATIONAL AMPLIFIER; SC70-8
31 U5 - 1 SG-3030-JF-32.768000KHZ-B EPSON 32.768KHZ OSCILLATOR; SMT; 32.768KHZ;
32 PCB - 1 MAX
ANALOG DEVICES
PCB PCB:MAX
33 C8, C24-C26, C28, C29 DNP 0 N/A N/A OPEN PACKAGE OUTLINE 0603 NON-POLAR CAPACITOR
34 R8, R15-R17 DNP 0 CRCW06031003FK; ERJ-3EKF1003 VISHAY DALE/PANASONIC 100K RESISTOR; 0603; 100K; 1%; 100PPM; 0.10W; THICK FILM
134
TOTAL
