Anatel A643a - Instrument Installation 19 of 220
RPS - June 2007 - Edition 12
Anatel Operator Manual
2 Instrument Installation
2.1 General Information
All models of the Anatel A643a Analyzer are designed to provide a flexible method of
monitoring ultrapure water systems. The basic Anatel A643a–S configuration consists of an
Analyzer and a C80 Controller. These two components are combined with a printer on the
Anatel A643a–P to form a portable analysis system. Additional Analyzers and Controllers can
be integrated to create a local area network (see “Network Installation” on page 39).
This configuration flexibility necessarily affects installation of the Anatel A643a System.
Each Analyzer is furnished with an Installation Kit (Anatel A643a–S: P/N FG2041101; Anatel
A643a–P: P/N FG2041201) and must consider these preparatory and installation issues:
Note that these procedures are common to most, but not all, Anatel A643a components.
The C80 Controller, for example, is built into the portable Anatel A643a–P Analyzer and,
consequently, does not require external communications connections. Conversely, a
Sensor Name cannot be assigned to a stand-alone C80 Controller because it is not integral
to the Anatel A643a–S Analyzer.
Table 2-1 : Preparatory and installation issues
Procedure C80 Anatel A643a–S Anatel A643a–P
Inspection X X X
Verification X X X
System Time X — X
Sensor Name — X X
Mounting X X —
Plumbing — X X
External Communications X X —
Auxiliary I/Os — X X
Power X X X
Self-Cleaning — X X
