TX7+现场准备手册 TX7+ Site Preparation Manual
10
6.2 卸除步骤 Removal Procedure
第一步 Step 1.
小心将从机床上切除包装袋。
Remove the Seet Bag from the machine by carefully cutting it off.
第二步 Step 2.
检查震动指示器的颜色。在正常情况下显示为红色，但 TX7+如在运输中掉落或受
损，震动指示器就会显示为蓝色。
Check the color of the ‘Shock’ indicators. Normally, they are RED. If
your TX7+ has been dropped or damaged during transportation, the
indicators will turn BLUE.
如震动指示器显示为蓝色，请立刻通知 ANCA 公司。
Please notify ANCA immediately if any of the indicators have
turned BLUE!
第三步 Step 3.
将 TX7+从托板上卸除下来，需将连接机床至托板的校平螺栓旋开。这些螺栓分别
位于主托板轨道顶部凸缘下方的七个位置。需使用一只 24 毫米的套筒板旋开螺
栓。
To separate the TX7+ from the sled, unscrew the leveling bolts
attaching the machine to the sled. These bolts are found in 7 places
under the top flange of the main sled rails. A 24mm socket is
necessary to remove these bolts.
