ANCEL FX2000 - 5.2 System Diagnosing

FX2000 User's Manual
13
Automatic
(Note: This mode allows
your tool to scan the vehicle
test system automatically)
Manual Select
(Note: In this case, you need to choose the
desired system manually. Just follow the
on-screen instructions to proceed.)
5.2 System Diagnosing
This function is specially designed to diagnose electronic control system of
single vehicle model which includes the following systems:
• ENG (Engine)
• ABS (Anti-lock Brake System)
• TCM (Transmission Control Module)
• SRS (Supplemental Restraint System)
Notes:
• Before diagnosing, please make sure the diagnostic program corresponding to certain
vehicle model has been installed on your FX2000.
• For vehicles manufactured by different vendors, it is possible that it has different
diagnostic menus. For details, please follow the instructions on the screen to proceed.
Refer to the flowchart illustrated as below to diagnose a vehicle:
Select test system
Select VehicleModel
(Note: For different vehicles,
vehicle make selection may
differ. Generally, we can
choose a vehicle via make
year. But for BENZ, we need
to choose it via chassis.)
Read data stream
EN
Select test function
Select Vehicle
Manufacturer
Clear fault code
Read fault code
Read version
information
Select “Diagnose”
