-23-
-24-
In case that the outline size is changed, please refer to the real object.
13. Outline size
13-3 090 to 200AJR3-1 AJR3-1
14. Application range
ANDLI AJR3-1000 soft starter can meet the requirement that drives heavy loads, the below table
is only for reference.
Applicable loads
Centrifugal pump
Ball mill
Fan
Light load motor
Piston type
compressor
Elevating
machinery
Agitator
Crusher
Spiral type com
pressor
Spiral type belt
conveyer
Conveyer belt
Heat pump
Starting ramp
time (s)
Stop ramp
time (s)
Initial voltage
(%)
Voltage starting
(Max current-
limit value)
Current-
limit starting
The ANDELI AJR3-1000 soft starter can be connected with personal computer and plc through
build-in rs485 standard interface., it can proceed serial communication.
we can use the host command to start/stop the soft starter, it also can monitor its running state and
modify its function data etc..
please refer to the rs-485 operating manual about the detail communication content.
we can use rs485 communication of soft starter through a computer to proceed remote control,
order input, running state control and input the function data of many soft starters in one time.
main functions
input the stop order
monitor the running state
real-time trace (display the running information in a table)
read and write in the function code in one time, and keep it in the document.
please contact with us to negotiate the communication software.
15. RS485 communication
14-1 Sort of application load
13-3 250 to 500AJR3-1 AJR3-1

ANDELI AJR3-1005 Specifications
