（1 L1、3 L 2、5 L3）
（2 T1、4 T 2、6 T3）
（A2、B 2、C2）
A
017 - 3
380V
17KW
055 55KW
2/T 1 4/T 2 6/T 3
A2 B2 C2
1/L 1 3/L 2 5/ L3
准备 运行
故障
READY PASS PERROR
A
%
S
起动
RUN
设置
SET
确认
YES
停止
STOP
50 50
100
100
50
图2-2-1
TYPE AJR3-1017
POWEY 17 KW
VOLTAQE AC380V50HZ
RATED CURRENT
SER.NO
35 A
NAME SOFT STARTER
V
Hz
℃
M
-1- -2-
1. Concernment before operating
1-1 Inspection of incoming goods
After receiving the goods, please open the box to check the following items
to see if there is any problem on the products, if there is, or it is not your ordered
specification, please contact with the agent or the ANDELI office nearby.
Nameplate
Model of soft
starter
Rated voltage:
Standard motor capacity:
AC soft starter
Enterprise Code
Serial No.
017
Control box of circuit board
Coil in terminal of power
supply
Communication interface
Terminal of control circuit
Connect with bypass contactor
1-2 Product appearance
Machine base
Nameplate
Connect with the motor
Keyboard panel
2. Installation and wiring
2-1 Operating environment
Table 2-1-1 indicates the requirements for operating environment
Table 2-1-1
Standard :
Three-phase supply voltage (U)
Frequency
Suitable motor
Starting frequency
Degree of protection
Resistance to impact
Shock resistant capability
Ambient
temperature
Working temperature
Storage temperature
Ambient humidity
Max working height
Cooling system
Max operating angle relative
to the vertical installing position
AJR3-1000 develops the electronic soft start-soft stop
deviceand has passed the performance test, complies
with national standard: (GB14048.6-98)
50
Squirrel cage type three-phase asynchronous motor
Please do not exceed 20 times per hour.
Ip40 (Negotiable)
15g 11ms
Altitude below 3000m, the vibratory force device below 0.5G.
95% no condensation or drip
No capacity-fall when lower than 1000m (when higher than
1000m, add every 100m, the current will step down 0.5%)
Cooled by natural wind.
No requirement.
380-15% 415+10% 440-15% 500+10%
2-2 Installing method
The soft starter should be installed vertically, never install it in inversion, gradient or level.
Make use of screw to install it in a firm structure.
When the soft starter runs, it will produce heat, in order to get enough cooling air, please
remain a certain space according to the diagram 2-2-1 during design. The heat produced will
emanate upwards, so please do not install the soft starter under the equipments that are not
thermal-resistant.
Exhaust port
Admitting
port
JR 3
To check the specification that on the nameplate of soft starter.
Check the appearance to see if there is any damage that caused by transportation,
such as the outside cover and machine case. Also inspect the parts to see if there is
any damage or loose phenomenon.
Besides the soft starter, there is a copy of operating manual.
When carry the soft starter, please carry the machine body but not control box of
circuit board,
0...+ 40 no capacity-fall(+40~60℃，rise every 1℃,the
current will step down 1.2% )25...+70
