43
-
・☆ marked parts are consumable parts
・○ or ● marked parts differ among DDP-90E, DDP-90EN, DDP-120B，DDP-120BN respectively
consumables No. Part name Qty 90E 90EN 120B 120BN
1 Main body 1
○ ●
2 Lid 2
Differ all model
3
Adopter upper
1
○ ● ○ ●
4 plug with hex hole 4
○ ● ○ ●
5 Adopter lower 1
○ ● ○ ●
☆
6
Packing
4
○ ●
☆
7
Exhaust valve
2
○ ●
☆
8
O ring
4
○ ●
☆
9
Steel ball
4
○ ●
10 Joint 1
○ ● ○ ●
☆
11
Intake valve
2
○ ●
12
Bolt with washer
12
○
13
Bolt with washer
8
○
☆
14
Air operating valve
(spare parts set supplied with
No.26)
1
○
15
Hex. nut
2
○
16
Spring washer
2
○
17
Diaphragm holder-out
2
○ ●
18
Diaphragm holder-in
2
○ ●
☆
19
Diaphragm set
1
○ ●
☆
19-1
Diaphragm outside
2
○ ●
☆
19-2
Diaphragm inside
2
○ ●
☆
21
Y packing
2
○
☆
22
O ring
2
○
☆
23
O ring
2
○
☆
24
O ring
4
○
25 Rod 1
○
26 Bolt with hex. Hole 2
○
27 Muffler 2
○
28 Main body cover 1
○
29 Tapping screw 2
○
30 Name plate 1
○ ●
☆
31 Ball valve 1
○
☆
32 Pin 2
－ ●
