Product Functions
Document No. 992010. Issue 15 – 12.01.21
Page 14
19. Using the Transfusion Pole
The trolley is fitted with a loose transfusion pole (item 13, fig. 2) that can be fitted at
any point along the side bar and secured using the locking lever.
To adjust the height of the transfusion pole, as illustrated in fig. 16. Grasp the locking
mechanism (A) and using your thumb, lift the mechanism to release the lock and move
the pole up or down to the required height (B); release the mechanism to lock the pole
in any position.
The transfusion pole is fitted with two spring-loaded hooks that are designed to return
to their original, upright position, when not in use. Swivel one or both hooks outwards
(C) to hang the IV bags.
The maximum weight limit per IV hook is 3kg (6.6lbs) or 3 litres (101.4 fl oz),
and the safe working load for the IV pole is 6kg (13.2lbs).
