Anetic Aid QA4 - Patient Weight Limits and Load Capacity; Electrical Specifications and Requirements

Product Specifications
Document No. 992010. Issue 15 – 12.01.21
Page 5
C-Arm Traverse Range of Movement:
Head End Traverse
230mm (9.0”)
Foot End Traverse
230mm (9.0”)
Patient Weight Limits:
Trolley
250kg (550lb)
Head Section
25kg (55lb)
Leg Section
50kg (110lb)
Safe Working Load (SWL)
300kg (660lb)
NOTE: The trolley can be used in all positions with the maximum patient weight specified.
Standard Lightweight Leg Section:
Weight
6kg (13lb)
Articulation range
N/A
Articulating Leg Section (optional):
Weight
11kg (24lb)
Articulation range
0 – 45°
Electrical Specification:
Mains charging input (dependant on control box option)
230VAC, 50Hz, 1.3A
100VAC ± 10%, 50/60Hz, 2.5A
Battery specification
2 x lead acid cells, 24V, 4.5Ah
Standard mains lead
(This is the standard lead supplied, unless otherwise
specified at the time of ordering)
3m IEC C13 Socket to UK Plug,
Fused 5A
Full charge time from flat
8 hrs
NOTE: The charging figures quoted are dependent upon the age and condition of the
battery, and are guidelines only.
Electrical Classification:
The electrical classification for this product is; Class II Type B, fitted with a Functional Earth.
NOTE: The trolley is fitted with a functional earth connecting the mains inlet socket to the
base frame. Electrical Safety Enclosure Leakage tests will be inaccurate due to the functional
earth. The functional earth should be detached before performing Enclosure Leakage tests.
CAUTION: Ensure that the functional earth is reattached after testing.
EMC Compatibility:
Electromagnetic Compatibility: product conforms to IEC 60601-1-2:2014
Environmental Conditions:
Temperature:
Operation
10°C to 50°C
Storage & Transport
-20°C to 50°C
Relative Humidity:
Operation
30% to 75%
Storage & Transport
10% to 75%
Atmospheric Pressure:
Operation
70kPa to 106kPa
Storage & Transport
50kPa to 106kPa
Environmental Regulatory Information; WEEE, waste batteries, etc.
For the latest information about Anetic Aid’s environmental policy, WEEE policy, and the safe
disposal of this product, please refer to our website.
NOTE: All dimensions quoted are subject to the following tolerances; angles ±5°, lengths and
widths ±25mm (±1”), depths ±10mm (±0.4”). Anetic Aid reserves the right to change
specifications without notice.
