ANKO-OME-0005(A1)
61
C. Gearbox & dough extrusion system
Re:93.06.01
NO.
ITEM NO.
DESCRIPTION
NO.
ITEM NO.
DESCRIPTION
1
P-MCC08B-2
Chain 08B-2-46
43
P-SBS0808C
Inner Hex Bolt
2
P-SBF0620
Bolt
44
AP-HT4DAZ7001
Key 8*32
3
AP-HT4EMS7002
Chain gear of motor
45
AP-HT4DAX7001
2
nd
shaft
4
P-SBS0612C
Inner Hex Bolt
46
AP-HT4DAY7001
Key 6*32
5
P-MCC06B-1
Chain 06B-1-37
47
AP-HT4DAH7001
Washer
6
AP-HT5FMC7001
Cover
48
P-BR6005D
Bearing 6005
7
P-SCC-R47
Retainer
49
P-BS254010
Oil seal 25*40*10
8
P-BR6204D
Bearing 6204
50
AP-HT5DAC7001
Cover of 2
nd
shaft
9
AP-HT4FMT7001
Chain gear of 3
rd
shaft
51
AP-HT4EMT7001
Chain gear of motor
10
P-SBS0610C
Inner Hex Bolt
52
AP-HT5DAB7001
Inner cover of 2
nd
shaft
11
P-SCC-S24
Snap ring
53
AP-HT4DAI7001
Washer
12
AP-HT5SPS7001
Bolt for filling pump
locker
54
AP-HT4DAG7001
Gear of 2
nd
shaft
13
AP-HT5SPL7001
Filling pump locker
55
P-SBS0812C
Inner Hex Bolt
14
P-SCC-S18S
Snap ring
56
AP-HT5SPL7002
Stuffing pump locker
15
P-SNHM16
Nut M16*1.5
57
AP-HT1SPQ7001
Stuffing pump
supporting pin
16
Rubber pad
58
P-SWSHM8
Spring washer
17
AP-HT5GBP7001
Cover of gear box
59
P-SNHM10
Nut
18
P-SBH0512
Bolt M5*12
60
P-SWHM10
Washer
19
AP-HT4FMX7001
3
rd
shaft
61
P-SWSM10
Spring washer
20
AP-HT4FMY7001
Key 6*30
62
P-SBH1035
Bolt M10*35
21
AP-HT4FMZ7001
Key 5*17
63
AP-HT2DFC7001
Dough bucket
22
AP-HT4FDX7001
Transmission rod
64
AP-HT2DPH7001
Key 12*30
23
AP-HT4FDY7001
Key 5*30
65
AP-HT2DFN7001
Dough hopper
24
AP-HT5FDP7001
Connection tube
66
P-SBD0827
Two heads bolt
M8*11*8*8
25
P-SBH0625
Bolt M6*25
67
P-SNCM8
Acorn nut
26
P-BR6003D
Bearing 6003
68
P-SBD0832
Two heads bolt
M8*13*9*10
27
P-SBS0506
Inner Hex Bolt
69
AP-HT2DPA7001
Side dough propeller
28
AP-HT4FDS7001
Coupling
70
AP-HT2DPL7001
Cover for
29
AP-HT5GBC7001
Gear box
71
AP-HT2DPR7001
Dough propeller
30
AP-HT4DPX7001
1
st
shaft
72
AP-HT2DPU7001
Copper bushing of
propeller
31
AP-HT4DPY7001
Key 12*20
73
AP-HT2DSH7001
Dough sheathing
32
AP-HT4DPZ7001
Key 12*36
74
33
AP-HT4DPV7001
Washer
75
34
P-BR6209D
Bearing 6209
76
35
P-BS558012
Oil seal 55*80*12
77
P-KW-PM10
Cooling water
connector
36
AP-HT5DAF7001
Front cover
78
AP-HT2DPQ7002
Bushing for support
nozzle
37
P-SBF0614
Bolt
79
AP-HT2DPP7006
Support nozzle
38
AP-HT5DPB7001
Rear cover
80
AP-HT2DPN7001
Fix cover of support
nozzle
39
P-BR51209
Bearing 51209
81
AP-HT2DXT7006
Dough extrusion nozzle
40
AP-HT4DPW7001
washer
82
AP-HT2DXN7001
Fix ring cover of dough
extrusion nozzle
41
AP-HT4DPG7001
Gear of 1
st
shaft
83
P-BR6209D
BEARING 6209
42
AP-HT4DPT7001
Chain gear of 1
st
shaft
84
P-BOG-45
O Ring G45
