Chapter 7 Remote Commands
7-58
:SENSe:MEASure:EDIagram:DIAGram:TYPE?
Response <type>=<CHARACTER RESPONSE DATA>
POIN8, POIN16, POIN32, POIN64, POIN128
Function Queries the number of measurement points during Eye Diagram
measurement.
Example > :SENSe:MEASure:EDIagram:DIAGram:TYPE?
< POIN8
Compatibility Incompatible with existing models.
:SENSe:MEASure:EDIagram:DIAGram:ASEarch <setting>[,<mode>]
Parameter <setting>=<BOOLEAN PROGRAM DATA>
ON or 1 Auto Search ON
OFF or 0 Auto Search OFF
<mode>=<DECIMAL NUMERIC PROGRAM DATA>
1 Coarse
2 Fine
Note:
<mode> can be omitted. Coarse is specified when omitted.
Function Selects whether to execute Auto Search when starting the Eye Diagram
Measurement.
Example To set Auto Search to On when starting the Eye Diagram Measurement:
> :SENSe:MEASure:EDIagram:DIAGram:ASEarch ON,2
Compatibility Incompatible with existing models.
:SENSe:MEASure:EDIagram:DIAGram:ASEarch?
Response <setting>=<NR1 NUMERIC RESPONSE DATA>
0 OFF
1 ON (Coarse)
2 ON (Fine)
Function Queries whether to execute Auto Search when starting the Eye Diagram
Measurement.
Example > :SENSe:MEASure:EDIagram:DIAGram:ASEarch?
< 2
Compatibility Incompatible with existing models.
