Chapter 4 Window Operations
4-2
4.1 Configuration of Operation Screen
This section describes the items on the operation window for MP1862A.
Figure 4.1-1 Overall View of Operation Screen
The operation window is composed of six blocks as shown in Figure 4.1-1.
The function of each block is described in Table 4.1-1.
[1]
[
5
]
[3]
[4]
[
2
]
[6]
