Bytes to Follow: 0 bytes
Site Master Returns: 3 bytes
1) Volts peak-to-peak (higher byte)
2) Volts peak-to-peak (lower byte)
3) 255 (FFh) Operation Complete Byte
238 (EEh) Time-out Error
Set T1/E1 Receive Input Configuration Options - Control Word (A013h) (Option 50 only)
Description: Sets the Rx Input Configuration for the T1/E1 modes.
Bytes to Follow: 2 bytes
1) T1/E1 Measurement (00h: BERT, 01h: Vpp)
2) Rx Input Config
00h: Terminate
01h: Bridged
02h: Monitor +20 dB (BERT only)
Site Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid measurement or configuration
238 (EEh) Time Out Error
Set T1/E1 Measurement Duration - Control Word (A014h) (Option 50 only)
Description: Sets the measurement duration for the current mode (T1 or E1).
Bytes to Follow: 1 byte
1) Measurement Duration Index
00h: Manual
01h: 3 minutes
02h: 15 minutes
03h: 30 minutes
04h: 1 hour
05h: 3 hours
06h: 6 hours
07h: 12 hours
08h: 1 day
09h: 2 days
Site Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid duration or not in T1 or E1 mode
238 (EEh) Time Out Error
Set T1/E1 Data Logging - Control Word (A015h) (Option 50 only)
Description: Enables and disables data logging for T1/E1 modes. The ability to log data depends on the amount of available
memory.
Bytes to Follow: 1 byte
1) Data Logging Status
Site Master PM 101
