Anritsu Site Master S331D - Select Printer Type - Control Byte #30 (1 Eh)

141) E1 1
st
User Defined Loop Down (lowest byte)
142) E1 2
nd
User Defined Loop Down (highest byte)
143) E1 2
nd
User Defined Loop Down (lowest byte)
144) E1 User Defined Pattern (highest byte)
145) E1 User Defined Pattern
146) E1 User Defined Pattern
147) E1 User Defined Pattern (lowest byte)
148) E1 Bit Error Insert Value (1-1000) (higher byte)
149) E1 Bit Error Insert Value (lower byte)
150) E1 Frame Error Insert Value (1-1000) (higher byte)
151) E1 Frame Error Insert Value (lower byte)
152) E1 BPV Error Insert Value (1-1000) (higher byte)
153) E1 BPV Error Insert Value (lower byte)
154) E1 Graph Resolution
141
155) E1 Measurement Duration
142
156) E1 Voltage Measurement Scale (00h = Vpp, 01h = dBdsx)
157-240) Not Used
Select Printer Type – Control Byte #30 (1Eh)
Description: Select Printer Type.
Bytes to Follow: 1 byte
1) Printer ID
0 – Epson Stylus Models
1 – Epson LQ Models
2 – Citizen PN Models
3 – NEC Superscript Models
4 – NEC Silentwriter Models
5 – Seiko DPU 411, 414 Models
6 – Canon BJC 50
7 – Canon BJC 80
8 – Canon BJC 250
9 – Canon BJC 4400
10 – HP DJ 300 Series
11 – HP DJ 400 Series
12 – HP DJ 500 Series
13 – HP DJ 600 Series
14 – HP DJ 800 Series
15 – HP DJ 1120
16 – HP LJ 6L, 6P, 4000
17 – Epson Esc/P Compatible
18 – Epson Esc/P2 Compatible
19 – Epson Esc/P Raster Compatible
20 – HP PCL3 Compatible
Site Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
48 Site Master PM
141 Graph Resolution: 00h: Auto, 01h: 1 sec, 02h: 15 sec, 03h: 30 sec, 04h 45 sec, 05h 1 min, 06h: 15 min, 07h: 30 min,
08h: 45 min, 09h: 60 min
142 Measurement Duration: 00h: Manual, 01h: 3 min, 02h: 15 min, 03h: 30 min, 04h: 1 hr, 05h: 3 hrs, 06h: 6 hrs, 07h: 12
hrs, 08h: 1 day, 09h: 2 days
