1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid VBW Index
238 (EEh) Time Out Error
Set Spectrum Analyzer Sweep Mode – Control Byte #108 (6Ch)
Description: Enables or disables the Single Sweep Mode during Spectrum Analyzer mode of operation.
Single Sweep Mode activates once the Site Master exits from the remote mode.
For Single Sweep Mode during Site Master VNA modes of operation see control byte #11 (0Bh).
Bytes to Follow: 1 byte
1) Sweep Mode
00h – Single Sweep
01h – Continuous Sweep
02h – Video Trigger (Span must be 0)
03h – External Trigger (Span must be 0)
Site Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid Mode
238 (EEh) Time Out Error
Set Spectrum Analyzer Marker to Peak – Control Byte #109 (6Dh)
Description: Sets the specified marker to the peak value of the sweep.
Bytes to Follow: 1 byte
1) Marker Number (1-6)
Site Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid Marker Number
238 (EEh) Time Out Error
Set Spectrum Analyzer Marker to Center – Control Byte #110 (6Eh)
Description: Sets the center frequency equal to the frequency of the specified marker.
Bytes to Follow: 1 byte
1) Marker Number (1-4)
Site Master Returns: 1 byte
1) 255 (FFh) Operation Complete Byte
224 (E0h) Parameter Error: Invalid Marker Number
238 (EEh) Time Out Error
86 Site Master PM
