bit 5 : SPA Multiple Limit Upper Segment 1 Beep Level ABOVE/BELOW
53
bit 6 : SPA Multiple Limit Upper Segment 2 Status On/Off
bit 7 : SPA Multiple Limit Upper Segment 2 Beep Level ABOVE/BELOW
256) Status Byte 11 : (0b = Off/Beep if data is BELOW line , 1b = On/Beep if data is ABOVE line)
(LSB) bit 0 : SPA Multiple Limit Upper Segment 3 Status On/Off
bit 1 : SPA Multiple Limit Upper Segment 3 Beep Level ABOVE/BELOW
bit 2 : SPA Multiple Limit Upper Segment 4 Status On/Off
bit 3 : SPA Multiple Limit Upper Segment 4 Beep Level ABOVE/BELOW
bit 4 : SPA Multiple Limit Upper Segment 5 Status On/Off
bit 5 : SPA Multiple Limit Upper Segment 5 Beep Level ABOVE/BELOW
bit 6 : SPA Multiple Limit Lower Segment 1 Status On/Off
bit 7 : SPA Multiple Limit Lower Segment 1 Beep Level ABOVE/BELOW
54
257) Status Byte 12 : (0b = Off/Beep if data is BELOW line , 1b = On/Beep if data is ABOVE line)
(LSB) bit 0 : SPA Multiple Limit Lower Segment 2 Status On/Off
bit 1 : SPA Multiple Limit Lower Segment 2 Beep Level ABOVE/BELOW
bit 2 : SPA Multiple Limit Lower Segment 3 Status On/Off
bit 3 : SPA Multiple Limit Lower Segment 3 Beep Level ABOVE/BELOW
bit 4 : SPA Multiple Limit Lower Segment 4 Status On/Off
bit 5 : SPA Multiple Limit Lower Segment 4 Beep Level ABOVE/BELOW
bit 6 : SPA Multiple Limit Lower Segment 5 Status On/Off
bit 7 : SPA Multiple Limit Lower Segment 5 Beep Level ABOVE/BELOW
394) Status Byte 13:
(LSB) bits0-1:DTFWindowing Mode
bit: 1 0
||
0 0 - Rectangular (No Windowing)
0 1 - Nominal Side Lobe
1 0 - Low Side Lobe
1 1 - Minimum Side Lobe
bits2–7:NotUsed
395) Status Byte 14: (0b = Off, 1b = On )
(LSB) bit 0 : Fixed CW Mode On/Off
bit 1 : Site Master Cal On/Off
bit 2 : LCD Back Light On/Off
bit 3 : Measurement Unit Metric/English (0b = English, 1b = Metric)
bit 4 : InstaCal On/Off
bits 5 -7 : Not Used
396) Status Byte 15: (0b = Off, 1b = On)
(LSB) bit 0 : Antenna Factors Correction On/Off
bit 1 : Not Used
bit 2 : SPA Cal Status On/Off
bits 3-4 : Amplitude Units (00b = dBm 01b = dBV 10b = dBmV 11b = dBuV)
bits 5-6 : Detection alg (00b = pos. peak 01b = average 10b = neg. peak, 11b= sampling mode)
bit 7 : Not Used
397) Status Byte 16: (0b = Off, 1b = On)
(LSB) bit 0: Serial Port Echo Status On/Off
bit 1: Return Sweep Time On/Off
bit 2: RBW Coupling (1b = auto, 0b = manual)
bit 3: VBW Coupling (1b = auto, 0b = manual)
bit 4: Attenuation Coupling (1b = auto, 0b = manual)
Site Master PM 27
53 Beep level is always 1b for upper segmented limit line
54 Beep level is always 0b for lower segmented limit line
