Anritsu Site Master S331D - Page 73

254) OCC BW dBc (0-120)
255) Attenuation
238
(highest byte)
256) Attenuation
257) Attenuation
258) Attenuation (lowest byte)
259-274) Antenna Name (16 bytes in ASCII)
275) Status Byte 1: (0b = Off, 1b = On)
(LSB) bit 0 : Marker 1 On/Off
bit 1 : Marker 2 On/Off
bit 2 : Marker 3 On/Off
bit 3 : Marker 4 On/Off
bit 4 : Marker 5 On/Off
bit 5 : Marker 6 On/Off
bits 6-7: Not Used
276) Status Byte 2: (0b = Off, 1b = On)
(LSB) bit 0 : Not Used
bit 1 : Marker 2 Delta On/Off
bit 2 : Marker 3 Delta On/Off
bit 3 : Marker 4 Delta On/Off
bit 4 : Pre Amp Mode (0b = Manual, 1b = Auto)
bit 5 : Pre Amp Status On/Off
bit 6 : Dynamic Attenuation On/Off
bit 7 : Reserved
277) Status Byte 3: (0b = Off, 1b = On)
(LSB) bit 0 : Antenna Factor Correction On/Off
bits 1-2 : Detection alg (00b = pos. peak 01b = RMS Avg 10b= neg. peak, 11 = Sampling Mode)
bits 3-4 : Amplitude Units (log) (00b = dBm 01b = dBV 10b = dBmV 11b = dBuV)
(Linear) – (00b = Watts 01b = Volts)
bit 5 : Channel Power On/Off
bit 6 : Adjacent Channel Power Ratio On/Off
bit 7 : Units Type (0b = Log 1b = Linear)
278) Status Byte 4 (0b = Off/Beep if data is BELOW line, 1b = On/Beep if data is ABOVE line)
(LSB) bit 0 : Limit Type (0b = Single, 1b = Multiple)
bit 1 : Single Limit On/Off
bit 2 : Single Limit Beep Level (0b = beep when data is below line 1b = above)
bit 3 : Not Used
bit 4 : Multiple Limit Upper Segment 1 Status On/Off
bit 5 : Multiple Limit Upper Segment 1 Beep Level ABOVE/BELOW
bit 6 : Multiple Limit Upper Segment 2 Status On/Off
bit 7 : Multiple Limit Upper Segment 2 Beep Level ABOVE/BELOW
279) Status Byte 5 (0b = Off/Beep if data is BELOW line, 1b =On/Beep if data is ABOVE line)
(LSB) bit 0 : Multiple Limit Upper Segment 3 Status On/Off
bit 1 : Multiple Limit Upper Segment 3 Beep Level ABOVE/BELOW
bit 2 : Multiple Limit Upper Segment 4 Status On/Off
bit 3 : Multiple Limit Upper Segment 4 Beep Level ABOVE/BELOW
bit 4 : Multiple Limit Upper Segment 5 Status On/Off
bit 5 : Multiple Limit Lower Segment 5 Beep Level ABOVE/BELOW
bit 6 : Multiple Limit Lower Segment 1 Status On/Off
bit 7 : Multiple Limit Lower Segment 1 Beep Level ABOVE/BELOW
280) Status Byte 6 (0b = Off/Beep if data is BELOW line, 1b = On/Beep if data is ABOVE line)
(LSB) bit 0 : Multiple Limit Lower Segment 2 Status On/Off
bit 1 : Multiple Limit Lower Segment 2 Beep Level ABOVE/BELOW
bit 2 : Multiple Limit Lower Segment 3 Status On/Off
bit 3 : Multiple Limit Lower Segment 3 Beep Level ABOVE/BELOW
bit 4 : Multiple Limit Lower Segment 4 Status On/Off
bit 5 : Multiple Limit Lower Segment 4 Beep Level ABOVE/BELOW
Site Master PM 67
238 Value sent as (value * 1000)
