Connect the outlet hose
Insert the outlet hose in the air outlet in the
direction of the arrow.
FIG. 6
Preparation of adjustable window insert
1. Adjust the window insert to the size of the
window.
2. If the window is so long that it needs two
window inserts, use the screws to join the
window inserts when they are adjusted to
a suitable length.
FIG. 7
INSTALLATION
NOTE:
Choose one of the three installation methods
below for the outlet hose and the adjustable
window insert.
Vertical sliding window
1. Cut the self-adhesive foam rubber seals
A and B to a suitable length and fasten
them on the jamb and window frame as
shown in the diagram.
FIG. 8
2. Place the window insert in the window
opening.
FIG. 9
3. Cut the non self-adhesive foam rubber
seal C to a suitable length for the width
of the window. Place the seal between
the glass and the jamb to prevent air and
insects coming into the room.
FIG. 10
4. If necessary t the safety fastener with the
2 screws as shown in the diagram.
FIG. 11
5. Place the window insert adapter in the
hole in the window insert.
FIG. 12
Horizontal sliding window
1. Cut the self-adhesive foam rubber seals
A and B to a suitable length and fasten
them on the jamb and window frame as
shown in the diagram.
FIG. 13
2. Place the window insert in the window
opening.
FIG. 14
3. Cut the non self-adhesive foam rubber
seal C to a suitable length for the height
of the window. Place the seal between
the glass and the jamb to prevent air and
insects coming into the room.
FIG. 15
4. If necessary t the safety fastener with the
2 screws.
5. Place the window insert adapter in the
hole in the window insert.
FIG. 16
Wall mounting
1. Make a hole with a diameter of 125 mm
in the wall for the wall outlet adapter B.
2. Fasten the wall outlet adapter B to the
wall with the 4 supplied screws and plugs.
3. Connect the outlet hose (with wall outlet
adapter A) to wall outlet adapter B.
FIG. 17
NOTE:
• Fit the adapter cover over the hole when
the air conditioner is not in use.
• For best functionality do not stretch or
bend the hose. Check that there are no
obstacles within 50 centimetres of the
air outlet, otherwise the outlet system
will not work properly. The diagrams in
