Ansmann Racing X8 - Page10.ai

- 10 -
Lenkung / Steering / de direction
115000741 5x55 Turnbuckle
115000706 6.8 Ball stud
………2 ……………2 ……………2
115000706 6.8 Ball stud
1:1 x1
115000706 6.8 Ball End-Steering
……………4
1:1 x1
Steering-Right
Steering-Left
Approx.31.5mm
Approx.31.5mm
▲Projection.Note direction
▲Projection.Note direction
Front Upper Turnbuckle-Left
Front Upper Turnbuckle-Right
Steering Turnbuckle-Left
Steering Turnbuckle-Right
115000769
M3x16
115000769
M3x16
115000771
M3x25
115000771
M3x25
115000771
M3x20
115000762
M3
115000762
M3
115000762
M3
115000762
M3
14
115000741
115000706
115000706
115000706
115000706
5mm
115000771 M3x25 Screw
……2
115000769 M3x16 Screw
……2
115000762
M3 Nylon Nut
…………4
115000762
M3 Flanged Nylon Nut
………………2
……2
115000771 M3x20 Screw
