- 17 -
Heckflügel / Rear Wing Mount / aileron arrière
115000762 M3 Nylon Nut
…………………2
115000768 M3x18 Screw
…2
115000768 M3x16 Screw
……6
115000768
M3x16
115000768
M3x18
115000741 5x40 Turnbuckle
115000706 7.8 Ball End-Rear Upper
………2 ………4 ………………2 ……………2
115000706 7.8 Ball stud 115000706 7.8 Ball stud
115000712
▲Projection.Note direction
▲Projection.Note direction
1:1 x1
1:1 x1
Rear Upper-Left
Rear Upper-Right
115000741
115000706
115000706
115000706
115000706
Approx.16.5mm
Approx.16.5mm
115000768
M3x16
115000762
M3
115000768
M3x16
