- 20 -
Dämpfer / Shock Absorber / Amortisseur
115000724 / 115000725
18.5x1.5 O-Ring
……………4
T08623
Front-Short
Rear-Long
Front-Short
Rear-Long
115000724 /
115000725
18.5x1.5
115000727
Front Shock Spring-Short
Rear Shock Spring-Long
115000724 /
115000725
115000722
34
115000768 M3x18 Screw
…………………2
115000762 M3.5 Nylon Nut
………………………2
115000722 Plastic Bushing
……2
115000766 3.5x9x1 Washer
…………………2
115000768
M3x18
115000762
M3.5
115000766
3.5x9x1
115000722
L
R
F
R
x2
