Querlenker hinten / Rear Suspension / arrière triangle
115000762 M3 Nylon Nut
………………2
……………2
115000770 M4x10 Screw
………………4
115000705
3.1x9x2.5 Plastic Washer
……………2
115000744 3x51.5 Arm Pin
115000760
8x16x5 Ball Bearing
115000761
13x19x4 Ball Bearing
………2
………2
…………………2
115000738 M4x4 Screw
………………2
115000746 2.5x16.8 Pin
115000705 115000705
115000738
115000738
M4x4
115000760
8x16x5
115000761
13x19x4
115000746
2.5x16.8
115000746
L
R
115000762
M3
115000744
3x51.5
115000770
M4x10
115000705
3.1x9x2.5
L
R
115000708
Screw
Cement
