ORIGINAL OPERATING INSTRUCTIONS - ELECTRIC DRIVE FOR PEDELECS
38
To charge the battery, open the cap (3) on the charging socket (4) and
connect the plug (5) from the charger.
Once you have connected the charger to the battery, connect the charger
to the mains outlet with the power plug. The charger display lights up red
while charging; as soon as the battery is fully charged, the display lights up
green. The charging process is indicated on the battery itself by a flashing
LED on the capacity indicator ( only at the down tube battery).
Charge temperatur: 0°C bis 45°C
Charge time: ca. 5 to 7 hours (depends on battery capacity)
Storage: 5°C to 25°C (recommendation)
Storage: -20°C to 45°C (limit)
We recommend charging the battery after each trip. If the battery will not
be used for an extended period (such as over the winter), it should be char-
ged completely. To avoid damage to the battery, it should be recharged at
least every 12 weeks. It should be stored only in a dry place.
