3
Introduction
1.1 Quiet Computing™ Features
The Sonata IV is designed with Quiet Computing™ in mind. Many unique design features help
make this case quiet and cool.
1. Solid steel structure (0.8 mm thick steel).
2. Multiple compartments dedicated for motherboard and hard disk drives.
3. Unique hard drive mounting system for maximum noise reduction.
4. Side intake vents designed to maximize passive airflow.
5. Quiet 120 mm TriCool™ rear exhaust fan.
6. Built-in cable management to tuck away extra cables behind the drive cage.
7. Included 620-watt power supply with 120 mm double ball bearing low noise cooling fan.
1.2 Case Specifications
Case Type
Quiet Mini Tower
Color
Piano Black
Dimensions 17.3” (H) x 8.2” (W) x 18.8” (D)
440 mm (H) x 208 mm (W) x 478 mm (D)
Weight
21.1 lbs / 9.6 kg
Cooling
1 x rear 120 mm TriCool™ fan
Drive Bays 8 Drive Bays:
- 3 x 5.25” external
- 4 x 3.5” internal
- 1 x 2.5” internal
- 1 x 3.5” external drive bay bracket (Optional)
Motherboard Size
Mini-ITX, microATX, standard ATX
Front I/O Panel
2 x USB 2.0
1 x USB 3.0
AC’97 / HD Audio In und Out
1.2 Diagram
1. Rear 120 mm TriCool™ fan
2. Motherboard Mount: Mini-ITX,
microATX or standard ATX
3. 620W power supply
4. 3 x 5.25” external drive bays
5. 4 x 3.5” HDD trays
6. 1 x 2.5” SSD
7. Front I/O Panel
