Anybus Wireless Bolt Reference Guide

S Registers 81 (88)
Miscellaneous Registers (continued)
Register
Name
Value Range
Default Value
Description
Value 3: Auto (default) show WLAN if active
otherwise show BT if active
1008 Reserved
1009 Reserved
1010 Reserved
1011 Reserved
1012 Reserved
1013 Diagnose
Mode
0..4294967296 0x00010001 Set diagnose mode bitmask. The following events
will be sent when the bit is set:
Bit 0:
*WSCO - Connection to AP up
*WSCC - Connection to AP down
*WASA - Station has connected
*WASR - Station has disconnected
*WSDST - Digital signal transition (only applicable if
S4001 is 1)
*WSRSSC - RSSI value falls below or rises above
the value in S4003 (only applicable if S4004 is 0)
Bit 1:
*WSRSS - RSSI periodically sent while connected,
with interval set by S3007
*WSCH - Used WLAN channel, sent upon
connection setup
Bit 2:
*WSSCAN - Background scan result (only
applicable if S4004 is 0)
Note: Will not work while a connection is in
progress, use AT*WSCC to cancel
Bit 3:
*WSSCAN - Background scan result for possible
handover candidates (only applicable if S4004 is 0)
*WSRHC - Roaming handover candidate (only
applicable if S4004 is 0)
*WSRH - Roaming handover (only applicable if
S4004 is 0)
*WSFRG - Roaming reassociating (only applicable
if S4004 is 1)
*WSFRD - Roaming reassociated (only applicable if
S4004 is 1)
Bit 16:
*BCI - Connection indication (incoming connection)
*BCO - Connection opened
*BCC - Connection closed
*BDST - Digital signal transition (only applicable if
S2702 is 1)
*BLQC - Link Quality value falls below or rises
above the value in S2700
Bit 17:
*BLQ - Link Quality periodically sent while
connected, with interval 5000ms
Bit 18:
*BI - Background scan result, regardless of the
current roaming operation.
Bit 19:
*BI - When background scan is active results for the
currently connected device and possible handover
candidates are sent.
*BRSS - When background scan is active an
approximated RSSI value for the current connection
is sent periodically.
*BRHC - Roaming handover candidate
*BRH - Roaming handover
1014 Easy Config
Mode Timeout
0..4294967296 5000 Maximum time to wait for first push on SMART
button in milliseconds
Wireless Bolt
™
/ Wireless Bridge II
™
Reference Guide SCM-1202-004 EN 1.7
