Anybus Wireless Bolt Startup Guide

Technical Data 14 (16)
4 Technical Data
For complete technical specifications and regulatory compliance information
please visit www.anybus.com/support.
4.1 Hardware Specifications
Order code AWB2000 AWB2001
Color Black White top and black base
Wired interface type Ethernet
Connector Included plug connector
Antenna Internal dual-band 2.4 GHz and 5 GHz antenna
Maximum range 100 m (WLAN and Bluetooth)
Operating temperature Shadow: -40 to +65 °C
Direct sunlight: -40 to +45 °C
Shadow: -40 to +65 °C
Direct sunlight: -40 to +65 °C
Storage temperature -40 to +85 °C
Humidity EN 600068-2-78: Damp heat, +40°C, 93% humidity for 4 days.
Vibration See datasheet
Dimensions Height: 75 mm (95 mm incl. connector, 41 mm outside)
Diameter: 68 mm
Weight 81 g
Housing material Plastic (see datasheet for details)
Protection class Top (outside of host): IP67 / UL NEMA 4X
Base (inside of host): IP21
Mounting M50 screw and nut (50.5 mm hole needed)
Power supply 9–30 VDC (-5 % +20 %)
Cranking 12 V (ISO 7637-2:2011 pulse 4)
Reverse polarity protection
Power consumption 0.7 W idle, 1.7 W max.
