5. Once the scale has been powered on, it will go through an LCD display test
and it is ready for use when the display shows zero.
6. The scale requires about 15 minutes warm up before operation to ensure
best accuracy.
7. Please note when the battery symbol keeps on the screen, the batteries need
to be charged
4. Operation
4.1 Features and Specifications
*Large LCD display (digit height 30mm x 13mm) with LED backlight
*Kilogram (kg) and pound (lb) weighing modes
*Application include: simple counting , hold, accumulation
*Low power indication and auto power off / auto idle
Options: RS-232 or Serial printer
Load Cells
Minimum 350 ohm load cells
Maximum 1000 ohm
(Up to 4 load cells of 350 ohm)
Readability
Selectable, 0.0
Tare Function
Full
Units of measurement
Kg , lb
Power supply
7.4V/2500mAh Lithium Rechargeable battery or AC
adaptor 10VDC, 1000mA
Connector
4 pin d socket
4.2 Load Cell Connection
Load cell bus
Connector
Load cell wire
Wire socket
Red
J1
Red
E+
Yellow
J2
Black
E-
Blue
J3
Green
S+
Black
J4
White
S-
