MHPTV TX Quick Start Guide
MHPTV-QSG-DOC-V1.1, 12/05/2018 Page 20 of 37
1-PA 240VAC, Single-Phase AC Distribution Wiring
Properly connect the three wires to the terminal block as shown in the above diagram,
taking care to notice which terminal is connected to the chassis Ground in your
system. Be sure to connect the GND terminal properly and other two connections as
L1 and L2.
