MHPTV TX Quick Start Guide
MHPTV-QSG-DOC-V1.1, 12/05/2018 Page 17 of 37
8 AC Mains Connections
Please review the safety WARNINGS on page 4 of this manual before proceeding with
any electrical work.
A licensed Electrician is required to properly and safely connect the AC mains power
cable from your station's electrical panel to the terminal block located inside the TX AC
Mains Distribution compartment in compliance with local electrical and building codes.
Please note: a power cable is not provided with the Transmitter system and should be
obtained via your local Electrician.
Be sure the Main Breaker on the lower left front of the TX is turned OFF before performing any
electrical work on the TX (as shown below).
Main Breaker OFF
