MHPTV TX Quick Start Guide
MHPTV-QSG-DOC-V1.1, 12/05/2018 Page 8 of 37
4 TX System Description
A hi-level System Block Diagram of the MHPTV TX is shown below. The MHPTV
system essentially consists of an Exciter, a Controller (with built-in preamp),
1,2,3,4,5,6, or 8 Power Amplifiers with corresponding input Splitter and output
Combiner, and a Band Pass (mask) Filter.
.
