AOC 2236Swa Service Manual

72
C104 065G0402509 31 CHIP 5pF 50V NPO
C108 065G0402509 31 CHIP 5pF 50V NPO
C111 065G0402509 31 CHIP 5pF 50V NPO
FB405 071G 56G151 A CHIP BEAD 150 OHM
FB402 071G 56K121 M CHIP BEAD 120OHM 6A MGLB2012-120T-LF
FB401 071G 56V301 B CHIP BEAD 0805 300OHM BULLWILL
FB101 071G 59K190 M CHIP BEAD 0603 19R/500mA
FB102 071G 59K190 M CHIP BEAD 0603 19R/500mA
FB103 071G 59K190 M CHIP BEAD 0603 19R/500mA
D403 093G 64 42 L DIODE LBAV70LT1G SOT-23 LRC
ZD103 093G 39GA01 T RLZ5.6B
ZD104 093G 39GA01 T RLZ5.6B
709G3244 HS002 CONSUMPTIVE ASS'Y
715G3244 2 MAIN BOARD PCB
H52G 2191 1
美纹胶带
H52G1701 1 MESH PRINTTING_PAPER
KEPC8QR3 KEY G3371-2-X-X-1-090804
A33G0564 2 1L0100 Key-Guide
H52G1201 1 3M DOUBLE FACE TAPE
CN001 033G8034 6H H X WAFER 1.0mm SMT 6P
U001 056G 669 10 TOUCH KEY CG7246AMT QFN-16(COL)
R012 061G0603000 RST CHIP MAX 0R05 1/10W
R009 061G0603000 RST CHIP MAX 0R05 1/10W
R008 061G0603000 RST CHIP MAX 0R05 1/10W
R001 061G0603000 RST CHIP MAX 0R05 1/10W
R002 061G0603101 RST CHIPR 100 OHM +-5% 1/10W
R007 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R006 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R005 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
R004 061G0603561 RST CHIPR 560 OHM +-5% 1/10W
C001 065G0603102 31 CHIP 1000PF 50V NPO
C002 065G0603225 A5 CHIP 2.2uF 10V X5R
LED001 081G15BY 2 GP LED GPTD1204BOC1-A GP
ZD005 093G 39S 34 T UDZSNP5.6B ROHM
ZD004 093G 39S 34 T UDZSNP5.6B ROHM
715G3371 2 KEY BOARD PCB
PWPC9C41AHD2 POWER G2892-5-4-X-8-091118
GND1 009G6005 1 GROUND TERMINAL
CN602 033G3802 4 BH F CONNECTOR
CN804 033G8021 2E F CONNECTOR
CN803 033G8021 2E F CONNECTOR
CN802 033G8021 2E F CONNECTOR
CN801 033G8021 2E F CONNECTOR
040G 45762412B CBPC LABEL
IC902 056G 139 3A PC123Y22FZOF SHARP
NR901 061G 58100 X1 NTCR 10 20% 3.6W
C908 063G107K2246S1 X2 CAP 0.22UF K 275VAC
C822 065G 3J6806ET CAP CER 68PF J 3KV SL
C821 065G 3J6806ET CAP CER 68PF J 3KV SL
C819 065G 3J6806ET CAP CER 68PF J 3KV SL
C820 065G 3J6806ET CAP CER 68PF J 3KV SL
C817 065G 6J2096ET 2PF 5% SL 6KV
C902 065G305M1022BP CAP Y2 1000PF M 250VAC
C903 065G305M1022BP CAP Y2 1000PF M 250VAC
